Ground source heat pump


Ground Source Heat Pump
 -Capacity from 127 kW to 2450 kW.
- Reusable:Using solar energy stored in earth as cooling & heating source.
- Great environmental and economic benefit:No boiler or cooling tower;Less space, less CO2 and less initial investment.
- Acting as multi-function unit such as cooling, heating, sanitary hot water separately or simultaneously.
- Wide application as hotel, apartment, villa, factory, shopping center, office building, school, etc.
- Semi-hermetic screw compressor for mod.130 - 2500.Each compressor is equipped with a crankcase heater and a thermal overload cut-out;The screw compressor is also complete with a built-in electronic protection with temperature sensor located directly in the motor winding and on the discharge line.
- The refrigerant circuit is complete with sight glass, filter drier, high and low pressure gauges, solenoid valve, direct expansion valve, high and low pressure switch.
- Shell and tube dry expansion type condenser, factory insulated with flexible close cell material.
- Shell and tube type evaporator, factory insulated with flexible close cell material.
- The electric panel consists of compressor breaker, compressor contactor, phase sequence relay, control circuit breaker, microprocessor control with function display.
- LCD display, touch screen control panel.
- Automatic operation dramatically reducing maintenance cost thanks to reliable microprocessor system.
- For the units with semi-hermetic screw compressor, an infinitely variable capacity control system that is capable of exactly matching the demand requirement of the system is to be supplied.This system is to provide precise and stable control of supply water temperature over the complete range of operating conditions.
Model
TWWH-
130L
170L
200L
240L
260L
280L
310L
360L
380L
420L
Cooling capacity*
KW
130
170
200
240
260
280
310
360
380
420
Heating capacity*
KW
127
167
196
235
255
274
304
353
372
412
Power supply
380-415V/3Ph/50Hz
Compressor

Qty/refrigerant circuit
Nr.
1/1
1/1
1/1
1/1
1/1
1/1
1/1
1/1
1/1
1/1
Cooling power input*
KW
24
31
37
44
48
52
57
67
70
78
Heating power input*
KW
43
56
66
80
86
93
103
120
126
140
Energy adjustment steps
Step
25% - 100%
Max.Current for wiring
A
87
108
128
165
165
165
165
185
185
258
Refrigerant charge
Kg
23
30
36
43
46
50
55
64
68
75
Evaporator

Water side pressure
KPa
42
45
45
45
45
46
46
46
47
46
Pipe size
Mm
DN65
DN80
DN100
DN100
DN100
DN100
DN100
DN125
DN125
DN125
Water flow rate in cooling*
M3/h
22
29
34
41
45
48
53
62
65
72
Water flow rate in heating*
M3/h
9
12
14
17
18
19
22
